Maki, Atoms and Time Travel

To create animations for technical concepts, one is advised to use graphics software with a programmatic approach. While these provide the required precision, they suffer from an inherent disconnect between input and output. WYSIWYG programs avoid this detachment with interactivity at the cost of precision.

The purpose of this article is to outline how a program for interactive and programmatic animation development can be implemented. To experiment with different technologies and programming paradigms, I created a developmental implementation called Maki. This article outlines Maki's design decisions and discusses planned future development.

Table of Contents


  • Extensibility,
  • performance,
  • ease of use,
  • strict type and thread safety,
  • clear ownership and the
  • fear of loosing (type) information form Maki's main ideals.

I chose C++ because it enforces strict rules and offers handy containers, algorithms and many light-weight abstractions, aiding in the development of a complex system, without compromising on performance.

The goal of Maki is to allow the user to create 3D animations using Python; while the user is constructing their animation in an interactive shell, Maki shows the current status of the scene in a separate window. Here the user is able to freely move the camera. In addition to spacial movement, Maki provides the ability to jump in time; The user can decide which frame of the animation should be played.

This allows an easy to use workflow, minimizing the time between defining animations and playing with the results.


[video removed from print]

To start working with Maki, one has to initialize it. This defines the rendering API to be used and creates a window of the specified size.

[video removed from print]

Once that is done, you can create an atom. This call to add_cuboid_atom returns a handle to the cuboid. But you will see...that you don't see anything.

[video removed from print]

That's because you've only created the atom; you still have to tell Maki to actually render it. This call to show_cuboid_atom orders Maki to start showing the atom at frame 1.

[video removed from print]

We can also change the colour. Each call again needs to know what frame it should be applied to.

[video removed from print]

Our cube can also be moved. But Maki currently only supports instant movement—"teleporting" from one frame to the next.

[video removed from print]

Smooth transitions have to be implemented on the Python side. This quick implementation performs just that; it smoothly shifts the cube from frame 60 to frame 200.

[video removed from print]

As you can see, Maki currently shows the 199th frame. But now I'm applying another downward translation from frame 5 to 50. This downward shift lies in the past, so we expect the cube to be in a lower position in the present. And that's exactly what we see: The moment the shift is being applied, Maki performs a Chrono Sync and the cube changes it's position. The past was altered, and we see the repercussions in the present.

"The past was erased, the erasure was forgotten, the lie became truth."1984

Clear Ownership

Shared ownership, where multiple classes own a single resource, are convenient to implement; everything has access to everything, so the optimum of possibilities has been achieved. But those programs, in which everything owns everything and everything calls everything are very difficult to reason about and tend to be less performant.

When instead every resource is owned by only one object, that object's constructor acquires the resources and the destructor subsequently frees them. This programming technique (called RAII by the C++ committee for silly names) leaves no need for any garbage collection.

But in some situations the same resource has to be used by multiple objects. With an emphasis on used; these situations don't necessarily warrant the use of shared ownership. Instead the resource can be borrowed. For example, without going into detail of what these classes actually do: A RenderDriver owns a Renderer and an AtomDispenser. The AtomDispenser needs the Renderer to perform its task, so it borrows it from the RenderDriver. And because both the AtomDispenser and the Renderer are owned by the same RenderDriver, the AtomDispenser can rest assured that all its resources are (still) available.

This member function lends the Renderer to an AtomDispenser:

void AtomDispenser::create_all_atom_renderers(Renderer* renderer)

But not having to garbage collect isn't the only performance advantage. A clear ownership model also bestows a definitive purpose on each function and object. Objects are restricted to the resources they need to fulfill their task: Anything they don't need, they don't have access to. This reduces side-effects and consequently improves debuggability.

Knowing in which context what data is being used, allows the programmer to optimize memory accesses for just these contexts.

"Software does not run in a magic fairy aether powered by the fever dreams of CS PhDs."Mike Acton

Software runs on hardware, hardware that has certain tastes. So if you intend to write fast software, you should base your data layout on the silicon it's supposed to run on. Only because two concepts have something in common in the mental model of yours, doesn't mean their data representation has to have anything to do with each other. In fact they may vary wildly. That's why, what a concept's implementation should be based on, is the hardware in use, not the mental model of any programmer.

Therefore a clear ownership model is easier to reason about and the foundation for high performing software. Memory layout will also play a major role in Why Templates?.

Renderer Abstraction

Even though Maki is currently using OpenGL only, different rendering APIs (like Vulcan, Metal or DirectX) can easily be added. To achieve this many low-lever rendering concepts are implemented using abstract classes (e.g. Shader, Renderer and VertexBuffer). The actual API specific implementations (e.g. OpenGLShader) can be found in a subdirectory:

├── opengl
│   ├── opengl_buffer.cpp
│   ├── opengl_buffer.h
│   ├── opengl_renderer.cpp
│   ├── opengl_renderer.h
│   ├── ...
├── buffer.cpp
├── buffer.h
├── renderer.cpp
├── renderer.h
├── ...

The abstract classes define the static function create to create an instance of the appropriate class:

IndexBuffer* IndexBuffer::create(uint32_t count, const uint32_t* indices)
switch(Renderer::get_renderer_impl()) {
case Renderer::Implementation::opengl:
return new OpenGLIndexBuffer(count, indices);
MAKI_RAISE_CRITICAL("The requested renderer implementation is not supported.");
return nullptr;

The static function Renderer::set_renderer_impl is used to globally define the renderer API at Maki's boot up.

This decision, which renderer API should be used, is performed at runtime. That way the user can decide which implementation to use: Even so you're on Windows, you might want to use OpenGL instead of DirectX because you have custom shaders written in GLSL.

The situation is different for the platform, i.e. the window handling mechanism, which is selected based on the type of target system. GLFW can be used on Linux, Windows and the MacOS; WebAssembly might need something else. The crucial difference to the renderer API is that the decision, which platform is to be used, can be made at compile time. By using preprocessor statements to only compile the required platform, the switch statement can be avoided and some runtime overhead removed.

#if PROJECT == glfw
GLFWwindow* m_handle {nullptr};

This macro has to be set using the -Dplatform=glfw flag at compilation.

As you can see, extensibility lies at the heart of Maki.

Multi Threading

[video removed from print]

There are always two things happening concurrently:

  1. accepting new atoms or changing existing ones and
  2. rendering the scene or handling user interaction.

This is why it makes sense to use two threads, a control and a render thread. Since OpenGL doesn't allow multiple threads to use the same context, only the render thread is allowed to perform render calls. The control thread on the other hand is the only one Python can directly interface with. Consequently, data has to be safely exchanged between the two threads. In addition to that, each thread should under no circumstances be allowed to perform actions outside of its jurisdiction.

When Maki wakes up, the first order of business is to initialize the (main) control thread, after which the render thread is to be created. This initialization includes calling SET_THREAD_TYPE_CONTROL() and SET_THREAD_TYPE_RENDER() from the respective threads. These preprocessor macros define a thread local variable. Since each thread has it's own thread local variables, they can be used to deduce the type of any thread.

Every function can then be equipped with a call to MAKI_ASSERT_CTRL_THREAD() or MAKI_ASSERT_RNDR_THREAD(), which asserts that the correct thread is being used. Since these checks are being removed for Release mode and are only included in Debug builds (which can be specified using the -DCMAKE_BUILD_TYPE=Release flag) there is no runtime overhead.

#ifndef NDEBUG
MAKI_ASSERT_CRITICAL(g_thread_type == ThreadType::control, \
"This function can only be called from the control thread.")
MAKI_ASSERT_CRITICAL(g_thread_type == ThreadType::render, \
"This function can only be called from the render thread.")
// don't do anything in release mode

To prevent race conditions (uncontrolled, concurrent access to the same resource) mutexes are being used. These "mutual exclusion objects" allow the locking of a resource for the duration of its use. In addition to this locking operation being a rather expensive one, all other threads in need of that resource are being stalled. Therefore the use of mutexes ought to be minimized.

These two precautions, preventing the threads from running incorrect functions and accessing resources at the same time, form the basis for Maki's thread safety.


Just like how real atoms were thought to be the indivisible unit of the universe, atoms are the smallest renderable unit in Maki. A collection of them form a frame, multiple of which form an entire scene, which can be rendered to a video file.

An Atom stores all the data required to render that atom. This mainly includes vertex data, like position or colour.

struct Atom {
bool render {false};
// to be defined by implementation:
// static constexpr const char* type_name {"Atom"};
struct QuadrilateralAtom: public Atom {
std::array<vec3, 4> ver_pos {
vec3 {-1.0f, -1.0f, +0.0f}, // bottom left
vec3 {+1.0f, -1.0f, +0.0f}, // bottom right
vec3 {-1.0f, +1.0f, +0.0f}, // top left
vec3 {+1.0f, +1.0f, +0.0f}}; // top right
static constexpr const char* type_name {"Quadrilateral"};

The render flag, set to false, excludes the atom from the being-rendered-club.

Because Maki allows the user to jump in time, it needs to keep track of not only the current, but also any past and future frames. The simplest way of implementing this is to store all atoms for each frame. This results in a multitude of problems:

  1. A huge two-dimensional array is required. This can quickly drain all available memory or slow Maki to a crawl.
  2. When the user changes an atom at any frame, this atom and all future incarnations thereof have to be changed.
  3. A wait instruction, which simply leaves the scene as is, would consume as much memory as any other. More frames always mean more memory being consumed, no matter how much is actually happening in them.
  4. Adding a new atom means adding it to all frames.

Difference Array

To solve these problems I'm using a difference array. This difference array can be seen as the numerical derivative of the original array; instead of storing all atoms for every frame, I'm only storing how the atoms change from frame to frame. AtomDiffs define how an atom has to be altered to cross a frame-border (from one frame to the next, or back from the next to the current). Anything from applying a linear transformation, changing the color or just toggling the render flag, can be expressed with such an AtomDiff.

This functionality is implemented in the apply and reverse member functions. These take an atom and apply (or reverse) the changes this AtomDiff represents. Their m_id member variable can be used to determine the Atom this AtomDiff should be used for.

template<typename AtomType>
class ToggleRenderDiff: public AtomDiff<AtomType> {
explicit ToggleRenderDiff(uint32_t id)
: AtomDiff<AtomType> {id} {}
virtual void apply(AtomType& atom) const override
atom.render = !atom.render;
virtual void reverse(AtomType& atom) const override
atom.render = !atom.render;

Templating is used to accept any type of Atom. AtomDiffs are always immutable (always declared const).

This solves all of the aforementioned problems:

  1. Since AtomDiffs only contain the data absolutely needed to apply the represented change, they consume very little memory.
  2. When the user changes an atom at any frame, only one AtomDiff has to be created for that frame.
  3. When nothing happens in your scene, no AtomDiffs are being added and basically no memory is consumed; you can wait for as long as you like.
  4. Adding a new atom doesn't add another AtomDiff. Only all systems using the AtomDiffs should be made aware that a new atom exists.

The actual difference array is implemented in the AtomDiffLifetime. An AtomDiffLifetime contains one AtomDiffFrame for each frame. AtomDiffFrames are a container for all AtomDiffs belonging to that frame. The apply and reverse member functions take an entire list of Atoms as a parameter. The aforementioned m_id member variable is used to apply (or reverse) the correct AtomDiffs on the correct Atom.

void apply(std::vector<AtomType>& atoms) const
for(const AtomDiff<AtomType>* atom_diff: m_atom_diffs) {

Atom Chain

Being one of the central classes, an AtomChain contains all Atoms for one frame x. They can be seen as pointing to the frame x within the AtomDiffLifetime. To stick with the mathematical terminology, think of it as the integral from frame 0 to frame x. This "pointer" can freely be moved around to represent the requested frame. To achieve this, the underlying AtomDiffs owned by the AtomDiffLifetime are being used to approach the target frame.

void set_frame(
uint32_t frame,
const AtomDiffLifetime<AtomType>& atom_diff_lifetime)
while(m_frame < frame)
// adjust m_frame and call atom_diff_lifetime.apply
while(m_frame > frame)

The difference between an AtomChain and an AtomDiffFrame is that the AtomChain represents the absolute status of a frame. The AtomDiffFrame, on the other hand, defines how two consecutive frames differ.

There are always two atom chains in use for any type, a control and a render atom chain.

  • The render atom chain is needed to render the frame the interactive window requests.
  • To apply any absolute changes at frame x the control thread needs to know what the current state of frame x is. Otherwise it wouldn't know how to adjust the atoms in frame x-1 to become the new x. Thus the control thread needs its own atom chain.

The first frame is frame 0. It cannot display anything as it is used as the foundation for any following frames; you can see it as a defined constant of integration. Only subsequent frames can be the target of AtomDiffs.

Chrono Syncs

One might wonder what happens when the control atom chain changes a frame that lies before the render atom chain. This is exactly what happened in the Walkthrough. In this situation the render atom chain would be outdated, because its past changed. To fix this, Maki performs a chrono sync.

This means that the render atom chain evicts all of it's data and recreates all atoms with default member variables. Therefore it points to the 0th frame. Since none of the atoms in this frame have been changed, the default atoms currently in the render atom chain are correct— the render thread is synchronised again. To get back to where the render atom chain left off, it can use the already explained set_frame member function.


All functions and classes handling atoms are templated, so that all kinds of atoms can be accepted. But that also means that each AtomDiffLifetime can only handle one type of atom. Therefore multiple AtomDiffLifetimes are required to express the entire breadth of atom types.

Templated Memory

To conveniently access the correct AtomDiffLifetime, "templated memory" is being used:

class AtomDispenser {
// general declaration
template<typename AtomType>
AtomDiffLifetime<AtomType>& get_diff_lifetime();
AtomDiffLifetime<CuboidAtom> m_cuboid_diff_lifetime {};
AtomDiffLifetime<QuadrilateralAtom> m_quadrilateral_diff_lifetime {};
// specializations //
// for CuboidAtoms
inline AtomDiffLifetime<CuboidAtom>& AtomDispenser::get_diff_lifetime<CuboidAtom>()
return m_cuboid_diff_lifetime;
// for QuadrilateralAtoms
inline AtomDiffLifetime<QuadrilateralAtom>& AtomDispenser::get_diff_lifetime<QuadrilateralAtom>()
return m_quadrilateral_diff_lifetime;

The function AtomDiffLifetime<AtomType>& get_diff_lifetime() is actually nowhere defined. Only the specialized versions can be found, like AtomDiffLifetime<QuadrilateralAtom>& get_diff_lifetime<QuadrilateralAtom>. As you can see, the general type AtomType has been specialized with QuadrilateralAtom. This way the templating system decides which definition should be called, or fails when there is no specialization for the requested type.

Rendering Atoms

An AtomRenderer uses the underlying rendering abstraction to actually render an Atom. The implementation of such may vary wildly as each Atom has a different optimal way of being rendered. While some may use a common base class (like the BatchRenderer) others stand on their own.

The AtomRendererRouter is unfortunately needed to make these different implementations accessible from the templated world of Atoms.

template<typename AtomType>
struct AtomRendererRouter {
// can't be used unspecialized
typedef void type;
struct AtomRendererRouter<CuboidAtom> {
typedef CuboidRenderer type;
struct AtomRendererRouter<QuadrilateralAtom> {
typedef QuadrilateralRenderer type;

This router can be used like this to resolve Atom types to their respective renderer:

typename AtomRendererRouter<CuboidAtom>::type* m_cuboid_renderer {nullptr};

Being converted to this by the compiler:

CuboidRenderer* m_cuboid_renderer {nullptr};

(The {nullptr} is not necessary but always a nice touch ^^).

Why Templates?

[video removed from print]

Why not use an arguably much simpler object-oriented approach?

An AtomDiff can be applied to any Atom that provides the necessary member functions (an atom that doesn't have a color can't be painted red). So AtomDiffs are templated to suit any such Atom. Instead of using templates, I could have used an abstract Atom base class.

The problem with that lays in the way the Atoms are being accessed. Atoms are currently stored in an std::vector, which is the silly C++ way of saying "dynamic size array". There is one std::vector for each type of Atom. Memory allocated by an std::vector is always contiguous. Therefore the atoms lay side by side and the renderer, chewing through all atoms one at a time, gets sped up by the hardware prefetcher.

But this only works since the compiler knows the size of that type of Atom. If I were to use inheritance and a single std::vector of type Atom, the size of one of these Atoms isn't always the same. For example a Cube needs a lot more data than a triangle.

This can still be done of course. The way to do it is by storing pointers to the actual objects. Consequently, that the objects are scattered all over memory and the hardware prefetcher feels an urge to give up. In this case using contiguous memory amounts to a total performance increase of 35 to 60 (!!!) percent.

I could have still used multiple std::vectors with inheritance. But that means that all AtomDiffs and any other objects need to accept abstract types and potentially cast them down into more specific ones. This adds performance overhead, because any one function can't be optimized for one type of atom, and dynamic casting isn't exactly free. The main problem is that calling function discards information, which the called function has to painstakingly recreate. To put it in a nutshell, I'm incredibly afraid of loosing type information.

Path of an Atom

Let's wrap things up by looking at the path an atom takes, from the interactive Python shell to the screen.

  1. A cuboid gets created from Python using the add_cuboid_atom function, which gets redirected to RenderDriver::add_atom<CuboidAtom>. This creates a new default constructed CuboidAtom in the control and render AtomChain<CuboidAtom>s. Python receives an identifier with which it can apply changes to the atom.
  2. Since all default constructed atoms have their render flag set to false, our cuboid doesn't get shown. This flag gets checked in the draw_atom member functions in the respective AtomRenderer.
  3. We perform an operation on the cuboid, namely show_cuboid_atom, to start showing the atom in frame 3. To apply the requested change, the control atom chain is being moved to the 3rd frame.
  4. Now the newly created ToggleRenderDiff<CuboidAtom> can be added to the correct AtomDiffFrame. Because the control atom chain needs to stay synchronised, the new AtomDiff is being applied to it.
  5. The last task the control thread has to perform is to warn the render thread that something got changed. m_first_outdated_frame in the AtomDiffLifetime gets set to 3-1=2.
  6. Say our render atom chain is currently representing frame 5. Because 5>=2 a chrono sync has to be performed, after which the render atom chain is being moved back to frame 5.
  7. Now the CuboidRenderer has a new cube to render, which it does by using the underlying renderer API abstraction.

Conclusion and Future Plans

Currently Maki is a developmental example for the practical use of diff arrays, templates and multi threading. At the time being it isn't a usable program, though that might change in the future.

One of the biggest areas of development is adding more atoms. This includes bezier curves, spheres and LaTeX rendering. Any already implemented atoms can be improved with better shaders. Among other features, these would bring shadows and wireframe rendering to Maki. A more complicated aspect is morphing, which is required to smoothly transform atoms into different types. And lastly the user interface has to be greatly improved. The integration or reimplementation of an already existing graphics library is conceivable.

A major question of debate will concern weather any given feature should be implemented in C++ or Python.


You can find Maki's current status on GitHub at christopher-besch/maki. Maki's version as of this article's writing can be accessed here. Feel free to leave a star ^^
